TRENDNET TEG-ECTX GIGABIT PCI EXPRESS ADAPTER
Standards | · IEEE 802.3 10Base-T Ethernet · IEEE 802.3u 100Base-TX Fast Ethernet · IEEE 802.3ab 1000Base-T Gigabit · IEEE 802.3x, IEEE 802.1Q, IEEE 802.1p |
Standards | · Ethernet: UTP Cat. 3, 4, 5, EIA/TIA-568 100-ohm STP · Fast Ethernet: UTP Cat. 5, EIA/TIA-568 100-ohm STP · Gigabit: UTP Cat. 5, 5E, 6 EIA/TIA-568 100-ohm STP |
Protocol | · SNMP v1 |
Interface | · Port PCI Express / Gigabit Ethernet |
Power Consumption | · 2.3 watts (max) |
Diagnostic LED | · Link, activity |
Supported OS | · Windows 2000/2000 Server/XP(32/64-bit)/2003 Server/Vista (32/64-bit)/Win 7 (32/64-bit) · Novel NetWare Server 5.x / 6.x · Linux Kernel 2.4.x / 2.6.x |
Data Rate | · Ethernet: 10Mbps/20Mbps (half/full-duplex) · Fast Ethernet: 100Mbps/200Mbps (half/full-duplex) · Gigabit: 2000Mbps (full-duplex) |
Dimension | · 109 x 83mm (4.3 x 3.3in) |
Weight | · 80g (2.88oz) |
Temperature | · Operating: 0°C ~ 45°C (32°F ~ 113°F) · Storage: -10°C ~ 70°C (14°F ~ 158°F) |
Humidity | · 5%~95% (non-condensing) |
Certifications | · CE, FCC |
Package Contents | TEG-ECTX Multi-Language Quick Installation Guide CD-ROM(Drivers & User's Guide) |
- 1 x 10/100/1000Mbps Auto-MDIX WAN port
- PCI Express 1.0a compliant
- Incorporates Advanced Configuration Power Management Interface (ACPI) 2.0
- Wake-On-LAN (WOL)
- TCP segmentation / large send offload
- IEEE 802.1Q VLAN tagging and IEEE 802.1p Layer 2 priority tagging
- IEEE 802.3x full-duplex Flow Control
- Microsoft NDIS5 (IP, TCP, UDP) checksum off-load
- SNMP v1 supported
- Preboot eXecution Environment (PXE) 2.1 and Remote Program Load (RPL)
- Jumbo Frames up to 7K
- Intuitive cable diagnostic utility
