ANTEC 650W NE650G M 80+ GOLD FULL MODULAR POWER SUPPLY

warranty (months): 30

BND 178.00

650W Continuous Power – Guaranteed 650W of Continuous Power from Antec
100% Modular – Improves airflow and reduces clutter
80 PLUS® Gold certified -Reduce your electricity bill
PhaseWave Design – A server-class LLC design with a synchronous rectification based on a DC-DC topology
Antec Quality 7-year warranty
120mm Silent Fan – Whisper-quiet high-quality fluid-dynamic bearing fan with long life time
Zero RPM Manager – An advanced low voltage fan control with fan-off mode at low loads for absolute silence
99%+12V – Output for maximum CPU & GPU support
CircuitShieldï¼Full suite of industrial grade protections: OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO
High-Quality JP capacitors achieve unprecedented tight voltage regulation & low ripple & noise to maximize your system’s performance
28(18+10) pin MBU socket – For possible future MBU connectors
ATX 12V 2.4ï¼Engineered according to the newest PSU guideline and compatible with the latest CPU generation

Model	NE650G M 0-761345-11754-8 NE650G M GB
Type	ATX 12V 2.4
Modular	Fully
Dimension	150(L) x 140(W) x 86(H)
Input Voltage	100-240 VAC
Input Current	10A MAX
Input Frequency Range	50Hz-60Hz
PFC	Active PFC
Power Good Signal	100-500ms
Efficiency	Up To 92%
Protection	OCP / OVP / UVP / SCP / OPP / OTP / SIP / NLO
Output Capacity	650W
Operation Temperature	0~40°C
Regulatory	cTUVus / TUV / CB / RCM / CE / FCC
Fan	120mm Silence Fan
Certifications	80 Plus Gold
Connector	1 x MB 24(20+4) Pin 2 x 8(4+4) Pin EPS 12V 4 x 8(6+2) Pin PCI-E 8 x SATA 3 x Molex 1 x FDD
Net Weight	1.30 kgs
Gross Weight	2.50 kgs
Warranty	7 years
Note*	Price, feature and specifications are subject to change without notice
