GIGABYTE Z490 AORUS MASTER ATX MOTHERBOARD

CPU

AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series/ 3rd Gen Ryzen™/ 2nd Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ with Radeon™ Vega Graphics Processors

Chipset

AMD X570

Memory

·        4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory

·        Dual channel memory architecture

·        Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200(O.C.) / 2933 / 2667 / 2400 / 2133 MHz memory modules

·        Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules*

* ECC memory (ECC mode) support varies by CPU

·        Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

·        Support for Extreme Memory Profile (XMP) memory modules

(Please refer "Memory Support List" for more information.)

Onboard Graphics

Integrated Graphics Processor:

1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz

* Support for HDMI 2.0 version, HDCP 2.2, and HDR.

Maximum shared memory of 16 GB

Audio

Realtek® ALC887 codec

High Definition Audio

2/4/5.1-channel

LAN

Realtek® GbE LAN chip (10/100/1000 Mbit)

Expansion Slots

·        Integrated in the CPU (PCIEX16):

· AMD Ryzen™ 5000 Series/ 3rd Gen Ryzen™ Processors:

1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16

·        AMD Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series/ 2nd Gen Ryzen™ Processors:

1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16

* For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot.

·        2nd Generation AMD Ryzen™ with Radeon™ Vega Graphics processors/AMD Ryzen™ with Radeon™ Vega Graphics processors:

1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x8 Integrated in the Chipset (PCIEX4/PCIEX1)

1 x PCI Express x16 slot, supporting PCIe 4.0/3.0 and running at x4 (PCIEX4)

3 x PCI Express x1 slots, supporting PCIe 4.0/3.0

Multi-Graphics Technology

Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies

Note: For AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series/ 3rd Gen Ryzen™/ 2nd Gen Ryzen™ Processors only

Storage Interface

·        Integrated in the CPU (M2A_SOCKET):

· AMD Ryzen™ 5000 Series/ 3rd Gen Ryzen™ Processors:

1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0 x4/x2 SSD support)

·        AMD Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series/ 2nd Gen Ryzen™/ 2nd Gen Ryzen™ with Radeon™ Vega Graphics/ Ryzen™ with Radeon™ Vega Graphics Processors:

1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2 SSD support)

·        Integrated in the Chipset (M2B_SOCKET):

1 x M.2 connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 4.0/3.0 x4/x2 SSD support)

6 x SATA 6Gb/s connectors

Support for RAID 0, RAID 1, and RAID 10

USB

Integrated in the CPU:

4 x USB 3.2 Gen 1 ports on the back panel

Chipset:

4 x USB 3.2 Gen 1 ports available through the internal USB headers

6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers

Internal I/O Connectors

·        1 x 24-pin ATX main power connector

·        1 x 8-pin ATX 12V power connector

·        1 x CPU fan header

·        1 x water cooling CPU fan header

·        2 x system fan headers

·        1 x CPU cooler LED strip/RGB LED strip header

·        2 x addressable LED strip headers

·        2 x RGB LED strip headers

·        6 x SATA 6Gb/s connectors

·        2 x M.2 Socket 3 connectors

·        1 x front panel header

·        1 x front panel audio header

·        2 x USB 3.2 Gen 1 headers

·        2 x USB 2.0/1.1 headers

·        1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)

·        1 x Clear CMOS jumper

·        1 x Q-Flash Plus button

Back Panel Connectors

1 x PS/2 keyboard port

1 x PS/2 mouse port

1 x HDMI port

4 x USB 3.2 Gen 1 ports

2 x USB 2.0/1.1 ports

1 x RJ-45 port

3 x audio jacks

I/O Controller

iTE® I/O Controller Chip

H/W Monitoring

Voltage detection

Temperature detection

Fan speed detection

Water cooling flow rate detection

Overheating warning

Fan fail warning

Fan speed control

BIOS

1 x 128 Mbit flash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features

·        Support for APP Center

* Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.

@BIOS

EasyTune

Fast Boot

Game Boost

ON/OFF Charge

RGB Fusion

Smart Backup

System Information Viewer

·        Support for Q-Flash Plus

·        Support for Q-Flash

·        Support for Xpress Install

                                  Bundled Software

Norton® Internet Security (OEM version)

Realtek® 8118 Gaming LAN Bandwidth Control Utility

Operating System

Support for Windows 10 64-bit

Form Factor

ATX Form Factor; 30.5cm x 24.4cm

Remark

•             Due to different Linux support condition provided by chipset vendors, please download Linux driver from chipset vendors' website or 3rd party website.

•             Most hardware/software vendors may no longer offer drivers to support Win9X/ME/2000/XP. If drivers are available from the vendors, we will update them on the GIGABYTE website.
