TRENDNET TEG-S16G 16-PORT GIGABIT GREENnet SWITCH (RACK MOUNT)-UNMANAGED

Standards

·         IEEE 802.3 10Base-T

·         IEEE 802.3u 100Base-TX

·         IEEE 802.3ab 1000Base-T

·         IEEE 802.3x Flow Control

·         IEEE 802.3az Energy Efficient Ethernet

Network Media

·         Ethernet: Cat. 5 up to 100 m

·         Fast Ethernet: Cat. 5 and 5e up to 100 m

·         Gigabit Ethernet: Cat. 5e and 6 up to 100 m

Data Rate

·         Ethernet: 10 Mbps / 20 Mbps (half / full-duplex)

·         Fast Ethernet: 100 Mbps / 200 Mbps (half / full-duplex)

·         Gigabit Ethernet: 2000 Mbps (full-duplex)

Protocol / Topology

·         CSMA / CD, Star

Power Consumption

·         10.1 Watts (max.)

Switch Fabric

·         32 Gbps

Interface

·         16 x 10/100/1000 Mbps Auto-MDIX RJ-45 ports

Data RAM Buffer

·         512 KB

Filtering Table

·         8 K entries

Jumbo Frame Support

·         Up to 10 KB

Diagnostic LED

·         Power, 10/100 Mbps Link / ACT, 1000 Mbps Link / ACT

Power

·         100~240 VAC, 50/60 Hz Internal universal switching power

Dimension

·         440 x 140 x 44 mm (17.3 x 5.5 x 1.75 in.)

Weight

·         1.8 kg (3.8 lbs.)

Temperature

·         Operating: 0° ~ 40° C (32° ~ 104° F)

·         Storage: -10° ~ 70° C (14° ~ 158° F)

Humidity

·         Max. 90% (non-condensing)

Certifications

·         CE, FCC

Package Contents

TEG-S16g

Quick Installation Guide

Power cord (1.8 m / 6 ft.)

Rackmount hardware
