TRENDNET TK-803R 8-PORT RACK MOUNT USB/PS/2 KVM SWITCH

Management

8 Computers

Standard

USB 1.1 Compliant

PC Ports

8 x VGA HDB 15-pin (female)

Console Port

·         1 x USB (Type A) / PS/2 (6-pin Mini Din) Mouse

·         1 x USB (Type A) / PS/2 (6-pin Mini Din) Keyboard

·         1 x VGA HDB 15-pin (female)

Cable Interface
(Optional, not included)

·         To KVM

o    1 x VGA HDB 15-pin (male)

·         To PC

o    1 x VGA HDB 15-pin (male)

o    1 x USB (Type A)

Supported OS

Windows 98(SE)/ME/ 2000/XP/2003 Server/Vista/Windows 7, Linux, Mac and More

PC Selection

Hot-Key or Push Buttons

Auto-Scan Interval

10-100 seconds (Programmable through Hot-Key)

LEDs

On-line (Red), Select (Green)

Keyboard Status

Saved & Restored

Power Adapter

9V DC 1A External Power Adapter

Dimensions

407 x 165 x 45mm (16.0 x 6.5 x 1.8in.)

Weight

1.83 kg (4.0 lb)

Temperature

·         Operating: 0°C~40°C (32°F~104°F)

·         Storage: -20°C~60°C (-4°F~140°F)

Humidity

0%~80% (non-condensing)

Certification

CE, FCC

Package Contents

TK-803R

Multi-Language Quick Installation Guide

Power Adapter
(9V DC, 1A)

Rack Mount Kit
